GB18613-2020標準文件規定三相異步電動機各能效值
時間：2021-04-27
作者：山東左元
點擊：3834次
表1 三相異步電動機各能效等級
| 額定功率/KW | 效率/% |
| 1級 | 2級 | 3級 |
| 2極 | 4極 | 6極 | 8極 | 2極 | 4極 | 6極 | 8極 | 2極 | 4極 | 6極 | 8極 |
| 0.12 | 71.4 | 74.3 | 69.8 | 67.4 | 66.5 | 69.8 | 64.9 | 62.3 | 60.8 | 64.8 | 57.7 | 50.7 |
| 0.18 | 75.2 | 78.7 | 74.6 | 71.9 | 70.8 | 74.7 | 70.1 | 67.2 | 65.9 | 69.9 | 63.9 | 58.7 |
| 0.2 | 76.2 | 79.6 | 75.7 | 73 | 71.9 | 75.8 | 71.4 | 68.4 | 67.2 | 71.1 | 65.4 | 60.6 |
| 0.25 | 78.3 | 81.5 | 78.1 | 75.2 | 74.3 | 77.9 | 74.1 | 70.8 | 69.7 | 73.5 | 68.6 | 64.1 |
| 0.37 | 81.7 | 84.3 | 81.6 | 78.4 | 78.1 | 81.1 | 78 | 74.3 | 73.8 | 77.3 | 73.5 | 69.3 |
| 0.4 | 82.3 | 84.8 | 82.2 | 78.9 | 78.9 | 81.7 | 78.7 | 74.9 | 74.6 | 78 | 74.4 | 70.1 |
| 0.55 | 84.6 | 86.7 | 84.2 | 80.6 | 81.5 | 83.9 | 80.9 | 77 | 77.8 | 80.8 | 77.2 | 73 |
| 0.75 | 86.3 | 88.2 | 85.7 | 82 | 83.5 | 85.7 | 82.7 | 78.4 | 80.7 | 82.5 | 78.9 | 75 |
| 1.1 | 87.8 | 89.5 | 87.2 | 84 | 85.2 | 87.2 | 84.5 | 80.8 | 82.7 | 84.1 | 81 | 77.7 |
| 1.5 | 88.9 | 90.4 | 88.4 | 85.5 | 86.5 | 88.2 | 85.9 | 82.6 | 84.2 | 85.3 | 82.5 | 79.7 |
| 2.2 | 90.2 | 91.4 | 89.7 | 87.2 | 88 | 89.5 | 87.4 | 84.5 | 85.9 | 86.7 | 84.3 | 81.9 |
| 3 | 91.1 | 92.1 | 90.6 | 88.4 | 89.1 | 90.4 | 88.6 | 85.9 | 87.1 | 87.7 | 85.6 | 83.5 |
| 4 | 91.8 | 92.8 | 91.4 | 89.4 | 90 | 91.1 | 89.5 | 87.1 | 88.1 | 88.6 | 86.8 | 84.8 |
| 5.5 | 92.6 | 93.4 | 92.2 | 90.4 | 90.9 | 91.9 | 90.5 | 88.3 | 89.2 | 89.6 | 88 | 86.2 |
| 7.5 | 93.3 | 94 | 92.9 | 91.3 | 91.7 | 92.6 | 91.3 | 89.3 | 90.1 | 90.4 | 89.1 | 87.3 |
| 11 | 94 | 94.6 | 93.7 | 92.2 | 92.6 | 93.3 | 92.3 | 90.4 | 91.2 | 91.4 | 90.3 | 88.6 |
| 15 | 94.5 | 95.1 | 94.3 | 92.9 | 93.3 | 93.9 | 92.9 | 91.2 | 91.9 | 92.1 | 91.2 | 89.6 |
| 18.5 | 94.9 | 95.3 | 94.6 | 93.3 | 93.7 | 94.2 | 93.4 | 91.7 | 92.4 | 92.6 | 91.7 | 90.1 |
| 22 | 95.1 | 95.5 | 94.9 | 93.6 | 94 | 94.5 | 93.7 | 92.1 | 92.7 | 93 | 92.2 | 90.6 |
| 30 | 95.5 | 95.9 | 95.3 | 94.1 | 94.5 | 94.9 | 94.2 | 92.7 | 93.3 | 93.6 | 92.9 | 91.3 |
| 37 | 95.8 | 96.1 | 95.6 | 94.4 | 94.8 | 95.2 | 94.5 | 93.1 | 93.7 | 93.9 | 93.3 | 91.8 |
| 45 | 96 | 96.3 | 95.8 | 94.7 | 95 | 95.4 | 94.8 | 93.4 | 94 | 94.2 | 93.7 | 92.2 |
| 55 | 96.2 | 96.5 | 96 | 94.9 | 95.3 | 95.7 | 95.1 | 93.7 | 94.3 | 94.6 | 94.1 | 92.5 |
| 75 | 96.5 | 96.7 | 96.3 | 95.3 | 95.6 | 96 | 95.4 | 94.2 | 94.7 | 95 | 94.6 | 93.1 |
| 90 | 96.6 | 96.9 | 96.5 | 95.5 | 95.8 | 96.1 | 95.6 | 94.4 | 95 | 95.2 | 94.9 | 93.4 |
| 110 | 96.8 | 97 | 96.6 | 95.7 | 96 | 96.3 | 95.8 | 94.7 | 95.2 | 95.4 | 95.1 | 93.7 |
| 132 | 96.9 | 97.1 | 96.8 | 95.9 | 96.2 | 96.4 | 96 | 94.9 | 95.4 | 95.6 | 95.4 | 94 |
| 160 | 97 | 97.2 | 96.9 | 96.1 | 96.3 | 96.6 | 96.2 | 95.1 | 95.6 | 95.8 | 95.6 | 94.3 |
| 200 | 97.2 | 97.4 | 97 | 96.3 | 96.5 | 96.7 | 96.3 | 95.4 | 95.8 | 96 | 95.8 | 94.6 |
| 250 | 97.2 | 97.4 | 97 | 96.3 | 96.5 | 96.7 | 96.5 | 95.4 | 95.8 | 96 | 95.8 | 94.6 |
| 315~1000 | 97.2 | 97.4 | 97 | 96.3 | 96.5 | 96.7 | 96.6 | 95.4 | 95.8 | 96 | 95.8 | 94.6 |
